Alpha

• RECYCLED CONTENT
• PRODUCTION SITE
• INSTALLATION
• END OF LIFE
• VOC’S & CHEMICAL SUBSTANCES
• LIFE CYCLE ANALYSIS & COMPLIANCE TO GREEN BUILDING CERTIFICATIONS
• GREEN ENERGY
• PRODUCTION PROCESS
• HEALTH & COMFORT
• LIGHT REFLECTANCE VALUE

• CONSTRUCTION Tufted 1/10” Loop
• PILE MATERIAL 100% PA 6 Solution Dyed
• SECONDARY BACKING Back2Back: Modified bitumen enhanced with
• a thermoplastic elastomer, reinforced with
• a glass fibre fleece covered with 100% PES
• fleece. 10% recycled content included
• TOTAL WEIGHT Ca. 4 300 g/m²
• PILE WEIGHT Ca. 500 g/m²
• PILE ABOVE BACKING Ca. 302 g/m²
• TOTAL HEIGHT Ca. 5.8 mm
• PILE HEIGHT Ca. 2.6 mm
• PILE DENSITY Ca. 0.116 g/cm³
• TUFT DENSITY Ca. 171 600 /m²
• CLASSIFICATION EN 1307
• 33 - LC1
• CASTOR CHAIR SUITABILITY EN 985
• A: continuous use
• DONNÉES
• ENVIRONNEMENTALES
• Démarche HQE®: cf. FDES
• suivant NF P01-010
• Déclaration du 30/07/2003

• FIRE RESISTANCE EN 13501-1 Bfl -s1
• FASTNESS TO LIGHT ISO 105-B02 ≥ 7
• RUBBING FASTNESS EN ISO 105-X12 ≥4
• COLOUR FASTNESS TO WATER EN ISO 105-E01 ≥4
• THERMAL RESISTANCE ISO 8302 0.067 m² K/W
• IMPACT NOISE RATING ISO 10140 ΔL: 30 dB (1 000 Hz)
• SOUND ABSORPTION ISO 354
• Hz 125 250 500 1000 2000 4000
• αs 0.04 0.03 0.07 0.15 0.29 0.32
• PERMANENT ANTISTATIC ISO 6356 ≤2 kV
• TRANSVERSAL RESISTANCE ISO/DIS 10965 ≤109 Ohm
• SIZE & PACKING 50 cm x 50 cm box: 5 m² pallet: 20 boxes
• NUMBER OF COLOURS 14
• DIMENSIONAL STABILITY EN 986 max. 0.2%
• GUT-NR 982A6E5F
• LEED Product contributes toward satisfying Credit
• 4.3 under LEED®. Products are not reviewed under LEED®, LEED® credit requirements cover the performance of materials in aggregate, not the performance of individual products of brands. Fore more information on LEED®, visit www.usgbc.org/contact.
